Products / Lasers/Light / Fiber Amplifiers /

SIMTRUM Provides three types of fiber Amplifier including Erbium Doped Fiber Amplifier (EDFA) ,Ytterbium Doped Fiber Amplifier (YDFA), Thulium-Doped Fiber Amplifier (TDFA) for optical fiber communication where your optical signal need to be amplified.

Type	Wavelength	Input	Output
EDFA Single Mode C-Band - Standard/ Booster	1530 - 1565 nm	-45 dBm to -25dBm -6dBm to +3dBm	35@-35dBm / 45@-45dBm 15/17/20/23/25/26 dBm
EDFA Single Mode C-Band In-Line	1530 - 1565 nm	-25 dBm to +3 dBm	13/17/23/25/26 dBm
EDFA Single Mode C-Band Gain Flattened	1530 - 1565 nm	-32 dBm to -10 dBm	14/17/20/23 dBm
EDFA Single Mode C-Band High Power	1530 - 1565 nm	- 6 dBm to +10dBm	27/30/33/35/37/40 dBm
EDFA Polarization Maintaining C-Band PM - Low Power / High Power	1530 - 1565 nm	-30 dBm to +3 dBm - 6 dBm to +10 dBm	14/17/20/23/26 dBm 30/33/37/40 dBm
EDFA Single Mode C-Band Pulsed	1530 - 1565 nm	1-10mw	1-1000W
EDFA Single Mode L-Band High Power	1530 - 1603 nm	- 6 dBm to +10 dBm	27/30/33/37 dBm
EDFA Polarization Maintaining L-Band Low Power / High Power	1530 - 1603 nm	- 6 dBm to +3 dBm - 6 dBm to +10 dBm	15/17/20/23/25 dBm 27/30/33/37 dBm
EDFA Single Mode C+L Band Booster	1528 -1563 nm 1570 - 1603 nm	- 6 dBm to +3 dBm	17/20/23/25 dBm
YDFA Ytterbium Doped Fiber Amplifier	1030 - 1100 nm	0 dBm to 10 dBm	17/20/23/25/26/27/30/33/37/40 @0dBm
TDFA	1920 - 2020 nm	-10 to 10 dBm	20/23/25/26/27/30 dBm
Fiber Raman Amplifier 1st Order	1528 - 1565 nm	Pump Wavelenth 1425 - 1465 nm	Total Pump Power 300/500/1000/1400 mW
Fiber Raman Amplifier 2nd Order	1425 - 1465 nm	Pump Wavelenth 1340 -1360 nm	Total Pump Power 300/500/1000/1400 mW

Technical Support Available: Contact us | You can download our full Product Line Card Click Here
