Objective Lens
SIMTRUM provides a series of objectives for imcroscope application,including plan apochrmatic objective, industrial plan objective and biology plan objective.
| Name |
Magnification |
NA |
WD(MM) |
F(MM) |
R(um) |
Observation Method |
Level of Chromatic Aberration Correction |
| Plan Apochromatic Objective |
1X-100X |
0.025 to 0.9 |
0.4 to 41 |
2 to 100 |
0.3 to 11 |
/ |
Apochromatism |
| Industrial Plan Objective |
5X,10X,20X,100X |
0.13 to 0.9 |
1.1 to 20 |
2, 4, 10, 20, 40 |
0.31 to 2.1 |
Bright Field,
Bright and Dark Field |
Semi-apochromatism, Achromatism |
| Biology Plan Objective |
4X,10X,20X,40X,60X |
0.1, 0.13, 0.2, 0.3, 0.45. 0.6, 0.7, 0.75 |
0.6, 1.6-2.3, 2.3-3.3, 4, 7.7-8.9, 8.5, 14.5, 16.5, 20 |
3.3, 5, 10, 20, 50, 100 |
/ |
Bright Filed / Fluorescence,
Bright Field / Dark Field / Fluorescence |
Apochromatism,
Semi-apochromatism |
