Multi-Spectral Camera (400-850nm)

Please check the table below for individual specifications tied to individual products.

Product Brochure Link:RedEdge - MX | RedEdge - P | Dual Camera System | ALTUM-PT

                                                                             中文产品册:  RedEdge - MX | RedEdge - PDual Camera System | ALTUM-PT


Model

RedEdge - MX


RedEdge - P


Dual Camera System


ALTUM-PT


Weight231.9g (RedEdge-MX + DLS 2)350g (RedEdge-P + DLS 2)508.8g (Two sensors + Mount plate + DLS2 + Cable)

460g (16.2 oz.)

 Altum-PT + DLS2

Dimensions8.7cm x 5.9cm x 4.54cm
    (3.4in x 2.3in x 1.8in)

8.9cm x 7.0cm x 6.7 cm

(3.5in x 2.8in x 2.6in)

8.7cm x 12.3cm x 7.6cm
    (3.4in x 4.8in x 3.0in)
11.0cm x 8.0cm x 6.9 cm
    (4.3 in x 3.1 in x 2.7 in)
External Power4.2 V - 15.8 V7.0 V - 25.2 V4.2V DC - 15.8 V DC
    Provided through Dual Camera Mount
7.0 V - 25.2 V
Power Input4.0/8.0W
    (nominal, peak)
5.5/7.0/10W
    (standby, average, peak)
8.0/16.0W (nominal peak)
    Provided through Dual Camera Mount
5.5/7.0/10W (standby, average, peak)
Spectral BandsBlue   475(32), Green 560(27),
    Red 668(14), Red Edge 717(12),
    NIR 842(57)
Blue 475(32), Green 560(27),
    Red 668(14), Red Edge 717(12),
    NIR 842(57)
Coastal Blue 444(28)*, Blue 475(32), Green 531(14)*, Green 560(27), Red 650(16)*, Red   668(14), Red Edge 705(10)*,Red Edge 717(12), Red Edge 740(18)*, NIR 842(57)

Blue 475(32), Green 560(27),

 Red 668(14), Red Edge 717(12),

NIR 842(57)

RGB Output3.6 MP
    (global shutter, aligned with all bands)
5.1 MP
    (global shutter, aligned with all bands)
    *with appropriate post-processing
3.6 MP
    (global shutter, aligned with all bands)
12.4 MP (global shutter, aligned with all   bands)

Sensor

Resolution

1280 x 960 (1.2 MP per EO band)1456 x 1088 (1.6MP per MS band)
    2464 x 2056 (5.1MP panchromatic band)
1280 x 960 (1.2 MP per EO band)2064 x 1544 (3.2MP per MS band)
    4112 x 3008 (12MP per PAN band)
    320 × 256 thermal infrared
Ground Sample Distance8 cm per pixel (per band) at 120m (~400 ft) AGL7.7   cm per pixel (per MS band),
    3.98 cm per pixel (Panchro), at 120 m (~400 ft) AGL

8 cm per pixel (per band) at

 120 m (~400 ft) AGL

5.28 cm per pixel at 120 m

 (Multispec GSD)

    33.5 cm per pixel at 120 m

(Thermal GSD)

    2.49 cm per pixel at 120 m
    (Panchro & Pansharpened GSD)
Capture RateOne capture per second (all bands), 12-bit RAW

Up to three captures per second

 raw DNG

One capture per second (all bands), 12-bit RAW2 capture per second raw DNG*
InterfacesSerial, 10/100/1000 ethernet,
     removable Wi-Fi, external trigger,   GPS, SDHC
3 GPIO: Trigger input, top of frame out, 1 PPS out, host button. USB 2.0 port   for WiFi, serial, 10/100/1000 ethernet, and CF Express Storage.Serial, 10/100/1000 ethernet,
    removable Wi-Fi, external trigger, GPS, SDHC

3 configurable GPIO: select from trigger

 input, PPS input, PPS output, and top of frame signals. Host virtual button.

    USB 2.0 port for WiFi. Serial. 10/100/1000 Ethernet. CFexpress for storage
Field of View47°HFOV (multispectral)50° HFOV x 38° VFOV (MS)
    44° HFOV x 38° VFOV (PAN)
47° HFOV (multispectral)

50° HFOV x 38° VFOV (multispectral)

    46° HFOV x 35° VFOV(panchromatic)

    48o x 39o (thermal)
StorageSD CardCFexpress CardSD CardCFexpress Card



ALTUM-PT

THE MOST ACCURATE RESULTS AT LEAF-LEVEL RESOLUTIONS











Calibrated Multispectral Imagery

CRP 2: A new compact version of our Calibrated Reflectance Panel. Same functionality, now in a smaller size and easier to carry!

**Note: Each camera kit comes with the radiometric calibration tools you need to enable comparison over time.

DLS 2: Our next-generation light sensor, with cutting-edge technology for irradiance and sun angle measurements. It provides more accurate, reliable data, greatly reduces the need for post-processing, and substantially improves radiometric accuracy. With the integrated GPS, setup with any aircraft is simple.

Key Features:

INCREASED STORAGE
New professional removable storage standard in CFexpress, enabling over two captures per second, immediate turnaround time between flights by swapping cards, and super-fast card-to-computer upload speeds for more efficient data management.


TWICE THE SPATIAL RESOLUTION OF THE PREVIOUS ALTUM
Altum-PT features an ultra-high resolution panchromatic sensor which allows for “pan-sharpening” the multispectral imagery, ultimately increasing the spatial resolution of the multispectral data: 1.2 cm (0.47in) pan-sharpened ground resolution when flying at 60m (200ft).

UGRADETED THERMAL SENSOR
Altum-PT features a built-in 320 x 256 FLIR Boson® that enables thermal maps at twice the ground resolution of Altum - 17cm from 60m flight altitude.



Applications:

1. Irrigation Scheduling

2. Fruit Yield Estimations

3. Disease, Pest and Nutrient Deficiency Detection

4. Water Stress Prediction

5. Plant Phenotyping

6. Pressure Issues and Clog Detection in irrigation systems




SYNCHRONIZED THERMAL AND MULTISPECTRAL IMAGERY

The Altum-PT captures synchronized multispectral, thermal, and panchromatic data for pixel-aligned outputs at incredibly high resolutions. The capture of these bands happens simultaneously, eliminating the need for data alignment in post-processing.






































RedEdge-P

THE NEW STANDARD FOR DATA QUALITY AND REPEATABILITY


RedEdge-P uses purpose-built optics and industrial image sensors coupled with narrowband, scientific-grade filters. In addition, it undergoes a rigorous factory calibration process, creating a high-quality, calibrated, rugged tool for high-quality outputs.










CRP 2: A new compact version of our Calibrated Reflectance Panel. Same functionality, now in a smaller size and easier to carry!

**Note: Each camera kit comes with the radiometric calibration tools you need to enable comparison over time.

DLS 2: Our next-generation light sensor, with cutting-edge technology for irradiance and sun angle measurements. It provides more accurate, reliable data, greatly reduces the need for post-processing, and substantially improves radiometric accuracy. With the integrated GPS, setup with any aircraft is simple.



Key Features:

INCREASED STORAGE and keep the cameras with
New professional removable storage standard in CFexpress, enabling over two captures per second and the immediate turnaround time between flights by simply swapping cards.

SYNCHRONIZED CAPTURE OF HIGH-RES RGB AND MULTISPECTRAL
Simultaneous capture of up to six bands, enabling multiple high-resolution outputs such as RGB, crop vigor indices (NDVI, NDRE, etc), and high resolution panchromatic.

TWICE THE SPATIAL RESOLUTION OF THE PREVIOUS REDEDGE
With a high-resolution panchromatic imager, RedEdge-P enables higher-resolution RGB and multispectral outputs - 2cm resolution when flying at 60m. Spot smaller problems or features sooner and make more reliable management decisions across a variety of use cases.

WORKS WITH WHAT YOU HAVE (DRONES, PROCESSING, FLIGHT PLANNING)
This solution is compatible with a wide range of aircraft, from large fixed wings to small multirotors. Flight planning and data processing can be done with industry-standard tools.

RUGGED DESIGN
IP4X rated for dust and splash protection


Applications:

1. Plant Counting

2. Disease Identification

3. Phenotyping

4. Species Differentiation

5. Plant Health Mapping

6. Advanced Crop Scouting

7. Fertilizer Management

8. High-Res 3D Point Clouds


REDEDGE-P vs REDEDGE-MX

Data collected showing hay bales in the center of a field, taken by the new RedEdge-P (left) and RedEdge-MX (right) sensors for comparison.




THE SAME NARROW BANDS, AT TWICE THE RESOLUTION

This solution offers a seamless way to capture not just standard spectral bands but at a spatial resolution that takes it a step further. With a high-resolution panchromatic imager, RedEdge-P enables higher-resolution RGB and multispectral outputs - 2cm resolution when flying at 60m.











RedEdge-MX

THE SENSOR THAT DOESN'T COMPROMISE

RUGGED AND BUILT TO LAST



The right tool With its compact size, RedEdge-MX works well with both multirotor and fixedwing platforms. One flight is all it takes to generate RGB color, NDVI, and advanced vegetation index layers. And, because it is calibrated, you can get an accurate picture of change over time in every output.













RedEdge-MX: Compact, flexible, and powerful.

A rugged, built-to-last, professional multispectral sensor for agricultural drone mapping. Captures five spectral bands, and is one of the most flexible solutions on the market


KEY FEATURES:

CALIBRATED NARROW BANDS
Five narrow high resolution (8 cm/pixel at 400 ft) spectral bands captured during one flight. Calibrated for precise, repeatable measurements.

RUGGED AND DURABLE
New aluminum body for better durability and performance in higher temperatures. Global shutter imagers - no gimbal required and no moving parts.

FULL FLEXIBILITY
Compact size allows for integration with a wide variety of drones. Full access to raw data; outputs can be generated using a wide variety of processing and analysis platforms.



THE NEW COMPACT CRP 2

A new compact version of our Calibrated Reflectance Panel (CRP) with the same functionality, now in a smaller size and easier to carry! The CRP 2 in conjunction with our sensors enables more accurate compensation for incident light conditions. It has known reflectance values across the visible and near-infrared light spectrum. Capture an image of the CRP 2 before and after each flight to provide an accurate representation of light conditions during the flight!






















THE INDUSTRY STANDARD MULTISPECTRAL SENSOR

Providing a comprehensive view into crop health


With optimized GSD (resolution); the new DLS 2 light sensor; the ability to generate plant health indexes and RGB (color) images from one flight; and platform-agnostic data and integration, RedEdge-MX is one of the most flexible solutions on the market. An advanced sensor means that you can count on getting high quality, accurate data when you need it.


Key Benefits:

 - New aluminum body for better durability and performance in the heat.

 - Compact size allows for integration with a wide variety of drones.

 - Calibrated for precise, repeatable measurements.

 - Wide voltage range to handle more integrations without extra power conversion.

 - Rugged design with no moving parts.

 - Full access to raw data; outputs can be generated using a wide variety of processing and analysis platforms.


Applications:

 - Phenotyping

 - Species Differentiation

 - Crop Health Mapping

 - Weed Detection

 - Water Management

 - Advanced Crop Scouting

 - Fertiliser Management

 - Terrain Modeling

 - Disease Identification

 - Leak Scouting



The spectral resolution of the RedEdge-MX Multispectral Sensor

The MicaSense RedEdge-MX measures the light reflected in five different bands (red, green, blue, red edge, and near-infrared). More bands equal more sensitivity; which increases the potential for picking up variations in crop conditions.









RedEdge-MX Dual Camera Imaging System

Double the spectral resolution with half the hassle



Integrating two five-band cameras, the RedEdge-MX and the new RedEdge-MX blue, this solution enables the most advanced remote sensing and vegetation research applications.











RedEdge. MX blue

The performance you rely on from RedEdge-MX with a new coastal blue band, a new green band, and three new bands in the red to red-edge region of the spectrum.  Combined with the bands in RedEdge-MX, the 10 bands in the Dual Camera System enable direct comparison between satellite and drone data.

Already have a RedEdge-M or RedEdge-MX? Buy the new RedEdge-MX blue kit and get double the spectral resolution.









THE NEW COMPACT CRP 2

A new compact version of our Calibrated Reflectance Panel (CRP) with the same functionality, now in a smaller size and easier to carry! The CRP 2 in conjunction with our sensors enables more accurate compensation for incident light conditions. It has known reflectance values across the visible and near-infrared light spectrum. Capture an image of the CRP 2 before and after each flight to provide an accurate representation of light conditions during the flight!





















DIRECT DATA COMPARISON BETWEEN SATELLITE AND DRONE IMAGERY




Features:

 - Synchronized capture of all 10 bands for pixel aligned imagery

 - Standard 12-bit TIFF file outputs with embedded metadata for

   full access to raw data

 - Combined Downwelling Light Sensor and GPS for streamlined

   integration, accurate ambient light calibration. Only one DLS required.

 - Radiometrically calibrated spectral imagers for precise, repeatable

   measurements

 - Global shutters on all 10 lenses for distortion-free results on every

   platform

 - Comes standard with fixed bracket and quick-mount connector for

   easy integration

Benefits:

 - Compare imagery directly with Landsat and Sentinel satellite

   data

 - Data is easily processed using Pix4D, Agisoft, and other

   MicaSense data partners

 - Double the bands for double the analytical capabilities

 - Monitor shallow water environments with the new coastal blue

    aerosol band

 - Perform detailed analysis on chlorophyll efficiency with new red,

   green, and two new red edge bands strategically located on the

   red edge slope
