Model	Spectral Range	Resolution	Accuracy	Repeatability	Focal length	F/#	Slit Width
Standard Single Grating Monochromator	330~1000 nm	up to 0.5 nm	up to 0.5 nm	up to 0.25 nm	100 mm	F/3	300μm
High Resolution Single Grating Monochromator	330~1000 nm	up to 0.1 nm	up to 0.2 nm	up to 0.1 nm	300 mm	F/4.8	10μm~3mm
Double Grating Scanning Monochromator	200~2000 nm	up to 0.2 nm	up to 0.13 nm	up to 0.05 nm	150mm	F/4.5	10μm~3mm
Triple Grating Scanning Monochromator	200~2500 nm	up to 0.05 nm	up to 0.1 nm	up to 0.05 nm	300 mm	F/4.8	10μm~3mm
High Resolution Triple Grating Monochromator	200~2500 nm	up to 0.03 nm	up to 0.1 nm	up to 0.05 nm	500 mm	F/8	10μm~3mm
