	Availability	Reference Price
STPMS-0106TF468 STPMS-0106TF468，F-mount telecentric lens 0.106X, Max. sensor size 4/3''，Resolution 34.95 μm，Working Distance 468 mm	4-6 weeks	Request for quote
STPMS-024TF398 STPMS-024TF398，Standard Telecentric Lens 0.24X, Max. sensor size 35mm Film，Resolution 30.76 μm，Working Distance 398 mm	4-6 weeks	Request for quote
STPMS-0206TF468 STPMS-0206TF468，F-mount telecentric lens 0.206X, Max. sensor size 35mm Film，Resolution 21.16 μm，Working Distance 468 mm	4-6 weeks	Request for quote
STPMS-017TF416 STPMS-017TF416，F-mount telecentric lens 0.17X, Max. sensor size 35mm Film，Resolution 31.56 μm，Working Distance 416 mm	4-6 weeks	Request for quote
STPMS-1TF127 STPMS-1TF127，F-mount telecentric lens 1X Max. sensor size 35mm Film，Resolution 10.82 μm，Working Distance 127 mm	4-6 weeks	Request for quote

Model		STPMS-1TF127	STPMS-017TF416	STPMS-0206TF468	STPMS-024TF398	STPMS-05TF179
Magnification		1X	0.17X	0.206X	0.24X	0.5X
FOV (mm)(HxV)	Linear Array-2K (2K×10um)	20.0	120.6	99.5	85.4	41.0
	Linear Array-4K (2K×10um)	28.4	168.8	139.3	119.6	57.4
	Linear Array-8K (2K×10um)	40.0	241.2	199.0	170.8	82.0
	35mm	36.0x24.0	211.8 x 141.2	174.8 x 116.5	150 x 100	72.0 x 48.0
Resolution (μm)		10.82	31.56	21.16	30.76	18.18
F.No.		16	8	6.5	11	13
TV Distortion		0.01%
DOF		1.29mm	22.14mm	12.24mm	15.28mm	4.34mm
Dia./Width		88.5mm	288mm	238mm	203mm	114mm
Max.Sensor Size		35mm Film
Mount		F-Mount
Objective Side Telecentricity		<0.02°
Working Temperature		-10℃~+50℃

Model		STPMS-0106TF468
Magnification		0.106X
FOV (mm)(HxV)	1/3"	45.3 x 30.4
	1/2.5"	54.2 x 40.7
	1/2"	60.4x45.3
	1/1.8"	67.7 x 50.6
	2/3"	83.0 x 62.3
	1"	120.8x90.6
	4/3"	175.1x131.3
Resolution (μm)		34.95
F.No.		5.5
TV Distortion		0.02%
DOF		39.31mm
Dia./Width		238mm
Max.Sensor Size		4/3''
Mount		F-Mount
Objective Side Telecentricity		<0.02°
Working Temperature		-10℃~+50℃
