RTH600--SIMTRUM Photonics Store

Transmission Stage Upgrade
Upgrade stage from Reflection to Transmission, Standard hole size 2mm

6-10 Weeks

$500.00

Vacuum Chamber Upgrade
Upgraded vacuum chamber and interface (KF16), Temperature range -190 to 400℃.

6-10 Weeks

$1000.00

MINI RTH-250
Optical hot and cold stage, RT~250℃, no cavity, sample stage 20*20*4mm, price includes: mini hot stage, temperature controller, temperature control

6-10 Weeks

$1890.00

STPE120-25
Optical Cryo & High Temperature Stage, Temp control range -25 to 120℃, 40*40mm sample stage, copper, Semiconductor heating, Price includes: Temperature Stage and Controller, Water circulating system, Software.

6-10 Weeks

$4711.00

RTH1800
Optical Cryo & High Temperature Stage, Temp control rangeRT~1800℃ or even higher

6-10 Weeks

Request for quote

RTH1500
Optical Cryo & High Temperature Stage, Temp control range RT~1200℃/1500℃, Airtight chamber,Sample loading by crucible, crucible material optional ceramic, quartz, sapphire, etc., Price includes: Temperature Stage and Controller, Water circulating system, Software.

6-10 Weeks

$22670.00

RTH1000
Optical Cryo & High Temperature Stage, Temp control range RT to 1000℃, Stage 20*20mm, ceramic,Price includes: Temperature Stage and Controller, Water circulating system, Software.

6-10 Weeks

$17619.00

CRYO600-190
Optical Cryo & High Temperature Stage, Temp control range -190 to 600℃, Gas-tight Chamber, Loading platform: 20×20mm, Silver.Price includes: Temperature Stage and Controller, Chiller, LN2 Tank, Software.

6-10 Weeks

$12113.00

CRYO600-190-XY
Optical Cryo & High Temperature Stage, Temp control range -190 to 600℃, Gas-tight Chamber, Loading platform:20×20mm, silver.Displacement stroke ±6.5mm,Price includes: Temperature Stage and Controller, Chiller, LN2 Tank, Software.

6-10 Weeks

$13800.00

Optical Indicators	PE120-25	RTH600	CRYO600-190	CRYO600-190-XY
Cooling & Heating	Semiconductor cooling and heating	Resistance heating	Liquid nitrogen cooling, resistance heating
Temperature Control Range*	-25～120℃ OR -15～100℃ *	RT~600℃	-190～600℃ *	-190～600℃ *
Temperature stability	±0.1℃	±0.1℃	±0.1℃（> -120℃）	±0.1℃（> -120℃）
Temperature stability	±0.1℃	±0.1℃	±0.3℃（< -120℃）	±0.3℃（< -120℃）
Temperature Resolution	0.1℃
Temperature Control Speed	0～10℃/min (fixed point/program segment temperature control)	0～30℃/min (fixed point/program segment temperature control)，maximum 150℃/min
Temperature Control Method	PID
Temperature Sensor	PT100
Optical path	Reflected light path *Can be upgraded to transmitted light path
Window material	Quartz glass (manually removable and replaceable)
Window size	——	Φ25mm *
Objective lens working distance	Minimum 0.1mm	4.5mm *		5.2mm *
Light transmission hole	——	No light-transmitting hole by default
Light transmission hole	——	* Upgradeable to add φ2mm light-transmitting hole
Window defrost		Negative temperature air blowing defrosting
Sample stage size	40x40mm *	20x20mm *		φ20mm *
Sample stage material	Copper *Silver can be customized	Stainless steel	Silver	Silver
Overall dimensions	74x74x18mm *	91x97x24mm *		149x215x21.5mm *
Sample chamber height	——	3.5mm *		3mm *
Chamber	——	Airtight * Upgradeable vacuum chamber
Casing cooling	——	Circulating water
XY displacement stroke	——	——	——	±6.5mm

Sign In

Register

Retrieve password

RTH600

Optical Cryo & High Temperature Stage, Temp control range Room Temp to 600℃,Airtight chamber,Sample stage 20*20mm, stainless steel, Price includes: Temperature Stage and Controller, Water circulating system, Software.

MODEL:RTH600
